Vulcanized fiber discs (commonly known as fiber discs) are round grinding wheels with a backing made of vulcanized fiber that is coated on one side with resin and abrasive grain. Abrasive fiber disc is fitted to suitable backing pads and used on angle grinders, predominantly for machining metal.


The safety requirements applicable to fiber discs and their backing pads are laid down in the EN 13743 standard. The maximum surface speed (maximum operating speed) for fiber discs is 80 m/s.


As they can be combined with a wide range of grain types and backing pad versions, fiber discs have an extensive scope of applications ranging from rough machining to finish grinding of surfaces. The benefits fiber discs offer over abrasive mop discs and grinding discs are the elasticity of the backing, resulting in excellent adaptability, a fine and uniform scratch pattern (compared to grinding discs) and, first and foremost, their more affordable price.

Resin Fiber Sanding Discs

Specifications of Resin Fiber Disc

Their downsides in contrast with abrasive mop discs lie in their inferior service life and their relatively high sensitivity to moisture and temperature.

According to the abrasives grain, fiber disc include Aluminum Oxide, Silicon Carbide,

Zirconia, Ceramic and so on.


The size of resin fiber sanding discs include 4", 4.5", 5", 6", 7", 9" and so on.


The grit size of ceramic fiber disc is P16-P120. The most popular grit is P36-P120.


The hole pattern of carbon fiber disc include center round holes and center star shape hole.


The thickness of fiberglass grinding discs include 0.6mm and 0.8mm.


The application of carbon fiber disk usually include grinding wood, metal.


These general purpose fiber discs include models designed for use on wood, metal, casting, and stainless steel applications. Aluminum Oxide discs are designed for applications such as weld removal, grinding, blending, and polishing. Silicon Carbide discs are ideal for rough surfaces or nonferrous materials such as marble, china clay, fiberglass, enamel, porcelain, quartz, terrazzo, concrete, and epoxy.
